TM9900 Multiprotocol Multiband Mobile

FLEXIBLE, RELIABLE, MULTI-AGENCY COOPERATION

Significantly improve community safety outcomes with enhanced interoperability between first responders, schools, utilities and other public sector organizations with the TM9900, a highly versatile, highly reliable P25 mobile radio with the option for DMR and analog channels in multiple frequency bands.

Introducing the Tait TM9900 Multiband Multiprotocol Mobile Radio

‍

Seamless Multiband Performance

Tait 9900 series radios are configurable to operate on any combination of VHF, UHF, 7/800MHz and 900MHz bands, ensuring continuity in communications across agencies using different bands. Bands are not locked and can be reconfigured over the air at any time.

Maximum Connectivity

Connect to the full range of networks in current operations or future technology migrations including:

• Conventional analog
• P25 conventional digital
• P25 trunking phase 1 and 2
• DMR tier 2 and 3

A range of location services software options are supported by Tait 9900 series radios. GNSS hardware is standard in TP9900 and optional for TM9900.

Bluetooth audio and Wi-Fi OTAP (Over The Air Programming) are supported by TP9900 portables. TM9900 mobiles will support Bluetooth, Wi-Fi OTAP and 4G LTE options in a future release. Tait 9900 series radios also support OTAP via P25 or DMR Trunked networks. OTAP via Wi-Fi, P25 or DMR requires Tait EnableFleet.

Analog signaling includes two-tone decode, MDC1200, PL (CTCSS), DPL (DCS), and Selcall.

Why choose Tait 9900 Series?

Proven P25 and DMR Open Standard Interoperability

Designed to meet the TIA-102 P25 Compliance Assessment Program and the DMR ETSI standards for interoperability, Tait 9900 series radios offer the ability to switch between P25 and DMR networks just by changing the channel.

This level of interoperability has been proven to reduce incident response time with more effective, immediate communication between first responders and other public sector organizations.

Enhanced Worker Safety

All Tait 9900 units are equipped with inactivity timers (Lone Worker) to send automated safety alerts and a programmable emergency key for manual safety alerts while the TP9900 also has sensors to detect falls (Man Down). Combined with optional location services, dispatchers are better equipped to guide an effective response. Optional Tait Geofencing software also enables location-based workflow automation.

Extensive Voice and Data Capabilities

• 4,000 channels/100 zones shared between P25 and DMR modes
• 1000 P25 talk groups, supporting up to 2,000 members
• 300 scan groups with up to 50 members each and a maximum of 2,000 members
  Pre-set status messages
• Supports conventional and trunked IP data and P25 data such as GNSS location

Fully Secure End-to-End Encryption

Connect to Ensure only authorized personnel can hear your communications with highly secure end-to-end encryption management options, including:

• FIPS 140-2 certified module
• AES, DES and ARC4 algorithm
• Tait EnableProtect Advanced System Key
• Tait EnableProtect Key Fill Device
• Tait EnableProtect Key Management Facility
• Over The Air Rekeying (OTAR)

TM9900 Technical Specifications

Multiband Options

Operate across one or more frequency bands, including VHF (136-174MHz), UHF (378-520MHz), 700/800MHz (762–870MHz) and 900MHz (896–941MHz).

Output Power

VHF: 50W, 25W, 15W, 10W
UHF: 40W, 25W, 15W, 10W
700/800MHz: ≤806MHz: 30W, 25W,10W, 2W; >806MHz: 35W, 25W, 10W, 2W
900MHz: 30W, 15W, 5W, 2W

Channels/Zones

4,000 channels shared between P25 and DMR, 100 zones

Tait Tough

Military Standards for high humidity, sand & dust, vibration, shock, rain, solar radiation, and more. IP54 water and dust resistant. Operating temperature of -22°F to +140°F (-30°C to +60°C).

Dimensions

Body dimensions (DxWxH)
7.7 x 6.3 x 2.1in (195 x 160 x 52mm)

Weight

3.11b (1.4kg)
